This corrugated roof sheeting machine is a machine for producing corrugated roof sheets, which can process and press steel plates into corrugated roof panels through a series of processes. It is usually used in construction, industry and agriculture. It is made of high-quality metal materials, and its surface is treated with antirust powder, which makes it corrosion-resistant and can withstand the influence of bad weather conditions. In addition, its precise computer control system enables it to bend various thin or thick plates, providing high productivity and long-term reliability.
Features
This corrugated roof sheeting machine can produce high-quality steel silo board with excellent precision and accuracy, ensuring firmness and durability, and can withstand harsh industrial environment. The machine uses advanced technology to ensure that all materials are produced according to high standards, so that these steel plates have uniform specifications and good processability. In addition, the movement of the bending roller is hydraulic, which has the characteristics of high rolling speed and low energy consumption cost, and can improve the stability of processing.
1. Profile Drawing
2. Process Drawing
Passive decoiler - Feeding - Roll forming –- Cut to length -- Collection
3. Technical Information
3.1 Main power: 5.5kw
3.2 Reducer: BWD22-43-5.5KW
3.3 Transmission chain: 25.4 pitch
3.4 Wall frame thickness: 16mm
3.5 Machine size: about 7M*1.4M
3.6 Forming speed: 0-12m/min
3.7 Shaft O.D: φ80mm
3.8 Forming station: About 16
3.9 Blade material: Cr12
3.10 Heat treatment for blade: HRC HRC58-62°
3.11 Rolling thickness: 0.17-0.6mm
3.12 Length: 3m/±1.5mm
3.13 Roller material: 45# steel
4. Electrical Components and Hydraulic
4.1 Inverter: Thinget
4.2 PLC: Thinget
4.3 Operation panel: MCGS
4.4 Low electrical components: Deli
4.5 Encoder: Omron
4.6 Hydraulic station: 3kw
4.7 Oil pump: YBI-10
